SpringFamily - GO Motorsports Shop

Built for legend cars

GO Motorsports conveniently provides parts for Legend car racers which offers 8″ or 10″ length with a rate line-up from 140 to 350.

Below you'll find spring specs for their 10" length springs. Visit their website to find out more.

Learn more

GO Motorsports spring spec table


Spring Specs

Part #
Spring Rate
Usable Stroke
Max Stroke
Max Load
Purchase here
lbs/inch inch inch lbs
100-188-140
140
5.6
6.6
930
100-188-150
150
5.6
6.5
977
100-188-160
160
5.7
6.1
985
100-188-170
170
5.4
6.3
1,082
100-188-175
175
5.2
6.5
1,131
100-188-180
180
5.6
6.0
1,082
100-188-185
185
5.4
6.1
1,129
100-188-190
190
5.3
6.2
1,179
100-188-200
200
5.4
6.0
1,204
100-188-210
210
5.1
6.2
1,299
100-188-215
215
5.3
5.9
1,270
100-188-220
220
5.2
6.0
1,318
100-188-225
225
5.0
6.1
1,367
100-188-230
230
5.4
5.6
1,287
100-188-240
240
5.2
5.7
1,382
100-188-250
250
4.9
5.9
1,479
100-188-260
260
5.2
5.5
1,435
100-188-270
270
5.0
5.6
1,530
100-188-275
275
4.9
5.7
1,578
100-188-280
280
5.0
5.4
1,523
100-188-290
290
4.9
5.6
1,618
100-188-300
300
5.0
5.4
1,605
100-188-325
325
4.6
5.7
1,843
100-188-350
350
4.6
5.4
1,905
Swipe left for more info
